| •掃描功能 |
| •CTCSS/DCS非標亞音頻 |
| •尾音消除 |
| •電池省電功能 |
| •9級靜噪 |
| •中英文語音報號 |
| •一鍵破頻破碼功能 |
| 技術指標Specifications | |
| 頻率範圍 Frequency Range | 467.5125-467.6750MHz |
| 額定電壓Operating Voltage | DC3.7V (Li-ion battery) |
| 記憶頻道Memory Channels | 14 Channels |
| 天線阻抗Antenna Impedance | 50Ω |
| 頻率步進Frequency Spacing | 12.5/25 KHz |
| 電池容量Battery | 1500mAh |
| 工作溫度Working Temperature | -10°C ∼ +50°C |
| 尺寸Dimensions | |
| 重量Weight | |
| 發射部分Transmitting | |
| 輸出功率Output Power | 5W |
| 調制方式Modulation Mode | 16KΦF3E/11KΦF3E |
| 最大偏差Maximum Deviation | ≤5.0KHz |
| 雜散功率Stray Power | ≤7.5uW |
| 調制失真Modulation Distortion | <5% |
| 調制靈敏度Modulation Sensitivity | 8-12mV |
| 接收部分Receiver | |
| 靈敏度Sensitivity | ≤0.2uV |
| 鄰道功率Adjacent Channel Power | ≤-65dB(W) / ≤-55dB(N) |
| 音頻失真 Audio Distortion | ≤5% |
| 雜波抑制Spurious Response Rejection | ≥65dB |
| 音頻輸出功率Audio Power Output | ≥500mW |
